* There is an upcharge for these colors.** Due to variances in monitors, the above chart may not be an exact representation of EnviroMetal colors. For accurate colors, please request a hard copy from EnviroMetal, Inc.The colors represented here are standard Kynar 500® PVDF Resin-Based or Hylar 5000 based colors offered by EnviroMetal, Inc. Custom colors, metallic and mica based finishes are also available. Custom color matches have an up charge. Please contact EnviroMetal for price and delivery information. Metal panels available for final color approval. All colors shown are within limits of color chip reproduction.
PRODUCT DESCRIPTION Fluropon coatings are factory applied, oven-baked finishes based on polyvinylidene fluoride resin (Kynar 500® PVDF Resin-Based or Hylar 5000). Fluropon coatings are manufactured by Valspar, 701 S. Shiloh Rd., Garland, TX 75042-7812.Fluropon coating systems consist of primer, applied at a nominal dry film thickness of .25 mil, and a color coat, applied at a nominal dry film thickness of .75 mil. Some custom colors may require additional coats, such as a clear top coat and/or a barrier coat. Some aggressive environments may require additional coats, such as a clear top coat and/or a thick film primer. Contact EnviroMetal for suggested specifications.
PERFORMANCE Fluropon coatings on steel meet or exceed U.S. Army Corps of Engineers Section 07413 Metal Roofing & Siding requirements. Test results reported here are for G90 HDG. Detailed test results are available upon request.
| Color |
Initial Solar
Reflectance |
Emissivity
Value |
Solar Reflective
Index (SRI) |
| Seal Brown |
0.29 |
0.86 |
29 |
| Colonial Red |
0.30 |
0.86 |
30 |
| Hemlock Green |
0.35 |
0.85 |
36 |
| Evergreen |
0.16 |
0.86 |
12 |
| Dark Bronze |
0.28 |
0.90 |
29 |
| Brite Red |
0.46 |
0.85 |
51 |
| Patina Green |
0.37 |
0.85 |
39 |
| Felt Green |
0.10 |
0.84 |
3 |
| Surry Beige |
0.41 |
0.86 |
45 |
| Boysenberry |
0.18 |
0.86 |
14 |
| Teal |
0.29 |
0.86 |
29 |
| Slate Blue |
0.30 |
0.86 |
30 |
| Sandstone |
0.54 |
0.86 |
63 |
| Terra Cotta |
0.35 |
0.87 |
37 |
| Slate Gray |
0.40 |
0.86 |
43 |
| Regal Blue |
0.13 |
0.86 |
8 |
| Regal White |
0.70 |
0.85 |
80 |
| Buckskin |
0.38 |
0.85 |
40 |
| Granite |
0.37 |
0.88 |
40 |
| Matte Black |
0.07 |
0.86 |
0 |
| Copper Metallic |
0.49 |
0.84 |
55 |
| Silver Metallic |
0.58 |
0.78 |
66 |
| Weathered Galvalume |
0.30 |
0.82 |
29 |
| Champagne Metallic |
0.38 |
0.80 |
38 |
- Kynar 500 is a registered trademark of Arkema, Inc.
|
|
|
|
